Based on the award-winning SAPPHIRE NITRO+ RX 580 design, the SAPPHIRE NITRO+ RX 580 Special Edition has been factory overclocked at 1430 MHz boost engine with 8.4 GHz effective memory. Complementing the SAPPHIRE NITRO Gear custom backplate and shroud accessory family, the NITRO+ RX 580 Special Edition features a stunning metallic blue shroud and backplate lit up by a blue LED fan. Designed for quiet and powerful performance, the SAPPHIRE NITRO+ RX 580 Special Edition delivers to gamers the optimal 1440p gaming experience.
Fan Check.
- With NITRO+ models, SAPPHIRE has upped the stakes with its new Fan Check, which allows users to check the cooler's status via SAPPHIRE TriXX 3.0 software, and contact customer support in case of problems.
NITRO Quick Connect.
- SAPPHIRE’s Quick Connect System provides a quick and easy solution. If there’s a fan issue detected, the user doesn’t need to return the entire card – SAPPHIRE’s partners will send out a replacement fan directly to the customer or the retailer. Please contact your place of purchase to request a fan replacement. SAPPHIRE’s channel partner will arrange the ideal solution for you to receive your replacement fan.
Dual-X Cooling
- SAPPHIRE's acclaimed Dual-X Cooling is powered by two massive yet silent fans and state-of-the-art radiator design. The new form of our 95mm blades mean greater airflow and superior heatsink coverage at lower noise compared to standard cooling designs.
Technical Specifications:
GPU
- 2304 Stream Processors
- 14 nm
- 4th Graphics Core Next (GCN)
- 1430 MHz Boost Engine Clock
Memory
- 256 bit Memory Bus
- GDDR5 Memory Type
- 2100 MHz, 8400 MHz Effective
- 8 GB Size
BIOS Support
- UEFI BIOS
Displays
- Maximum 5 Outputs
Output
- 1 x DVI-D
- 2 x HDMI 2.0b
- 2 x DisplayPort 1.4
Resolution
- 5120×2880(60Hz) Pixel DisplayPort Resolution
- 2560×1600(60Hz) Pixel Dual Link DVI Resolution
- 4096×2160(60Hz) HDMI Resolution
API
- OpenGL® 4.5
- OpenCL 2.0
- DirectX® 12
- Shader Model 5.0
Feature
- AMD CrossFire
- AMD PowerTune
- FreeSync Technology
- AMD Eyefinity
- Quad HD Display (4K*2K Support)
- Video Codec Engine (VCE)
- AMD HD3D Technology
- Passive Cooling for Zero-noise Operation
- Component Heat Spreader
- 16K Hours Capacitor
- Dual BIOS
- AMD Tress FX Technology
- AMD Liquid VR Technology
- AMD Virtual Super Resolution(VSR)
- AMD TrueAudio™ Next Technology
- AMD Xconnect ready
- Universal Video Decoder (UVD)
- DirectX™ 12 Optimized
- Radeon VR ready Premium
- HDR Ready
- Frame Rate Target Control
- NITRO Fan Check
- NITRO Quick Connect system
- NITRO Glow RGB LED
- NITRO CoolTech(NCT)
- NITRO Free Flow
- Dual-X Cooling
- NITRO Boost
- Intelligent Fan Control III
- Black Diamond Choke 4
- Fuse protection
- Precision fan control
- Robust VRM Cooling
- Radeon Chill
- Radeon Relive
Cooling
- Dual-X fans
- Two ball bearing
Form Factor
- 2.2 Part Slot Occupied
- 260(L)X 135(W)X 43 (H) Dimension /mm
Power Consumption
- <250W
OS
- Windows 10, Windows 8/8.1, Windows 7
System Requirement
- 500 Watt Power Supply (Suggestion)
- 1 x 8-pin AUX Power Connector
- 1 x 6-pin AUX Power Connector
- Blue-ray™ / HD DVD playback requires Blu-ray / HD DVD drive.
- PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
