DVS capability
24bit/96kHz sound quality
OLED screen
Dual USB audio connections for software and audio devices
Connect MIDI based effects and instruments
Prime Professional 4-Channel Mixer X1800 PRIME Black
Recommend
Sort by
Rating
Date
Prime Professional 4-Channel Mixer X1800 PRIME Black
Description:
If you find an error in the description, please let us know!
Write a message
Send Report
If you find an error in the description, please let us know!
Specifications
Band Material
Master (balanced): +24 dBu (maximum), +4 dBu (unity) Master (unbalanced): +20 dBu (maximum), 0 dBu (unity) Booth: +24 dBu (maximum), +4 dBu (unity) Record: +10 dBV (maximum), -10 dBV (unity) Send: +10 dBV (maximum), -10 dBV (unity) Headphones: > 150 mW @ 40 Ω
Closure Type
Line: +15 dBV (maximum), 0 dBV (unity) Phono: -22 dBV (maximum), -40 dBV (unity) Microphone: -40 dBu (maximum), -60 dBu (minimum) Return: +15 dBV (maximum), 0 dBV (unity)
Compatiable With
CMRR: > 80 dB (@ 1 KHz, unity) PhEIN: < -124 dBu (Rs = 150 Ω, DIN)
Model Number
X1800 PRIME
Colour Name
Black
Printing Speed
Sampling Rate: 44.1, 48, 96 kHz Bit Depth: 24-bit
Machine Dimension
1.6” / 39 mm (diagonal) 1.4” x 0.69” / 35 x 17 mm (width x height) (2) monochromatic LED-backlit displays
Product Weight
7 kg
Product Height
445 mm
Product Length
310 mm
Product Width/Depth
109 mm
